Descripción
Technical Data | |
---|---|
GENERAL | |
Input connector | 4-pin, 3 mm pitch |
Input voltage max | 30 VDC |
Output connector | 4-pin, 3 mm pitch |
Conductor cross section | Stranded, cross section 4 x 0.20 mm2 (24 AWG) |
Cable outer diameter | 4.5 mm |
Maximum current | 2 A |
Weight | 47 g |
Total Length | 1000 mm |
Protection material | PVC 60P BLACK |
Flammability rating | UL 94 V-2 |
